schmersal ZV7H 236-11Z-RMS

schmersal ZV7H 236-11Z-RMS

6000 INR/Number
Get a Price/Quote

Product Details:

  • Application Position detection and monitoring
  • Mounting Type Panel/Surface Mount
  • Features Rugged design, easy to install, double insulation, complies with IEC standards.
  • Drive Type Plunger Actuator
  • Weight Approx. 100g
  • Phase Single Phase
  • Cable Length User defined (depends on installation)
  • Click to view more
Request To Call Back Send Inquiry
X

schmersal ZV7H 236-11Z-RMS Price And Quantity

  • 5000.00 - 7000.00 INR/Number
  • 1 Number
  • 6000 INR/Number
  • 90% relative humidity
  • Rectangular thermoplastic housing
  • 10A
  • Spring Plunger
  • Up to 10 million operations
  • 6 A gL/gG fuse required
  • 2 NC / 1 NO
  • Up to 1 million operations
  • ZV7H 236-11Z-RMS
  • IEC 60947-5-1
  • 250 V AC

schmersal ZV7H 236-11Z-RMS Product Specifications

  • Mechanical limit switch
  • -25C to +80C
  • 4A (AC-15, 230 V AC)
  • Screw Terminal
  • IP65
  • Manual
  • Yes
  • Snap Action
  • 50-60 Hz
  • User defined (depends on installation)
  • Single Phase
  • Approx. 100g
  • Rugged design, easy to install, double insulation, complies with IEC standards.
  • Plunger Actuator
  • Plastic, Metal (Housing and Actuator)
  • Panel/Surface Mount
  • Up to 240 V AC
  • Position detection and monitoring
  • 90% relative humidity
  • Rectangular thermoplastic housing
  • 10A
  • Spring Plunger
  • Up to 10 million operations
  • 6 A gL/gG fuse required
  • 2 NC / 1 NO
  • Up to 1 million operations
  • ZV7H 236-11Z-RMS
  • IEC 60947-5-1
  • 250 V AC

Product Description

Snap action with constant contact pressure up to switching point

1 Cable entry M 20 x 1.5

Thermoplastic enclosure

Good resistance to oil and petroleum spirit

Wide range of alternative actuators

30 mm x 58,5 mm x 30 mm




Reliable Mechanical Limit Switch for Industrial Applications

Purpose-built for position detection and monitoring, the Schmersal ZV7H 236-11Z-RMS delivers consistent reliability in automation systems. This switch withstands high humidity ( 90%) and operates within a wide temperature range (-25C to +80C), making it suitable for various industrial environments. Its rugged thermoplastic housing and metal actuator enhance durability, while IP65 ingress protection keeps it safe from dust and water.


Ease of Installation and Versatile Mounting

The ZV7H 236-11Z-RMS is designed for fast and straightforward integration. Panel or surface mounting, combined with screw terminal connections and customizable cable length, ensure flexibility for diverse installation requirements. Double insulation and snap action switching improve safety and operational accuracy, reducing downtime and maintenance costs.

FAQ's of schmersal ZV7H 236-11Z-RMS:


Q: How is the Schmersal ZV7H 236-11Z-RMS installed in automation systems?

A: The switch can be mounted on panels or surfaces using standard screws. Wiring is made easy with screw terminals, and the cable length can be set according to installation needs, making it adaptable for various industrial setups.

Q: What safety standards does the ZV7H 236-11Z-RMS comply with?

A: This limit switch conforms to IEC 60947-5-1 standards, ensuring high safety and performance requirements are met for industrial automation applications.

Q: When should I use a spring plunger actuator like the one in this model?

A: A spring plunger actuator is ideal for applications requiring precise position detection with consistent, repeatable actuation points, such as conveyor belt end stops or machine parts positioning.

Q: Where can the ZV7H 236-11Z-RMS be used considering its environmental ratings?

A: With its IP65 protection and wide operating temperature range, this switch is suitable for most factory and industrial environments where resistance to dust, moisture, and temperature variations is vital.

Q: What process should be followed for short circuit protection with this switch?

A: To ensure proper protection, install a 6 A gL/gG fuse in series with the switch, as recommended by the manufacturer. This protects the limit switch against potential short circuits.

Q: How does the snap action control benefit my application?

A: Snap action switching ensures quick, reliable contacts with minimal lag, enhancing operational precision and minimizing wear, especially in repetitive or high-speed applications.

Q: What are the main usage and benefits of choosing this limit switch?

A: The ZV7H 236-11Z-RMS is primarily used for position detection and monitoring in industrial automation. Its rugged design, ease of installation, long service life, and compliance with international standards make it a dependable and cost-effective solution for manufacturers and system integrators.
