Safety Light Curtains

12000 INR/Number

Get a Price/Quote

Product Details:

Remote Control Yes
IP Rating IP65
Connectivity Type Wired
Frequency 50/60 Hz
Phase Single Phase
Control Type Microprocessor Based
Sensor Type Photoelectric Beam
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Safety Light Curtains Price And Quantity

Price Range 10000.00 - 15000.00 INR/Number
Minimum Order Quantity 1 Number
Price 12000 INR/Number

Detection Capability Up to 14mm (finger protection), up to 30mm (hand protection)
Alignment Indication LED Display
Maximum Sensing Distance Up to 12m (model dependent)
Synchronisation Automatic and Optical
Operating Humidity 35% 95% RH, non-condensing
Enclosure Material Anodized Aluminum Housing
Output Type PNP/NPN, Relay Output
Protection Height 150 mm to 1200 mm (model dependent)
Number of Beams Varies by model (10 48 beams)
Response Time 10 ms 25 ms

Safety Light Curtains Product Specifications

Weight ~700 g (per unit)
Mounting Type Panel/Bracket Mount
Power 24V DC, <5W
Cable Length 2m, extendable
Automation Grade Automatic
Features Finger and Hand Protection, Self-Testing, Easy Alignment, Quick Response
Application Industrial Safety, Machine Guarding, Presses
Material Aluminum Alloy, Polycarbonate
Processor Type Embedded
Remote Control Yes
IP Rating IP65
Connectivity Type Wired
Phase Single Phase
Frequency 50/60 Hz
Sensor Type Photoelectric Beam
Voltage 24V DC 10%
Control Type Microprocessor Based
Temperature -10C to 55C

Detection Capability Up to 14mm (finger protection), up to 30mm (hand protection)
Alignment Indication LED Display
Maximum Sensing Distance Up to 12m (model dependent)
Synchronisation Automatic and Optical
Operating Humidity 35% 95% RH, non-condensing
Enclosure Material Anodized Aluminum Housing
Output Type PNP/NPN, Relay Output
Protection Height 150 mm to 1200 mm (model dependent)
Number of Beams Varies by model (10 48 beams)
Response Time 10 ms 25 ms

Product Description

MODEL- EOS2
Automatic Start/Restart. Two safety PNP static outputs, auto-controlled. All connections and configurations through M12 5-pole connectors. Unshielded cables up to 100 meter long. Start/Restart interlock and EDM through external AD SR1 interface. Muting function through external AD SRM interface. Autotest every 0.5 sec.

Advanced Safety for Industrial Applications

Engineered for the highest degree of machine safety, these light curtains safeguard personnel while maximizing production efficiency. With self-testing and fast response features, they protect operators' fingers and hands during hazardous tasks. Compatible with presses and other machinery, these devices help manufacturers in Italy and worldwide comply with safety standards, reducing workplace accidents and production downtime.

Reliable Performance and Flexible Integration

Designed to perform in harsh environments, the curtains operate efficiently from -10C to 55C and 35% to 95% relative humidity. Easy alignment via LED indicators and various mounting options simplify installation. These curtains accept 24V DC input, support PNP/NPN or relay outputs, and interface seamlessly with modern automation systems for thorough machine guarding.

FAQ's of Safety Light Curtains:

Q: How do I determine the right protection height and model for my machine?

A: Select the protection height based on the machine area that needs coverage, from 150 mm up to 1200 mm. The number of beams and detection capability required (14 mm for finger or 30 mm for hand protection) should match your specific safeguarding needs. Consult the manufacturer or supplier for model recommendations tailored to your application.

Q: What is the process for installing and aligning the safety light curtains?

A: Installation is straightforward using the supplied panel or bracket mounts. The curtains feature an LED alignment display, making setup and beam adjustment intuitive. Follow the included guide to ensure optimal alignment and automatic optical synchronization for reliable light curtain performance.

Q: Where can these light curtains be used within industrial settings?

A: Ideal for machine guarding in presses, packaging lines, or automated assembly, these curtains are suitable for use wherever operator safety from moving mechanical parts is critical. Their rugged anodized aluminum construction and IP65 rating make them compatible with harsh industrial environments.

Q: What are the main benefits of using these light curtains for machine guarding?

A: They offer rapid response times, high detection accuracy for finger and hand protection, and ease of integration with existing control systems. Their self-testing and reliable operation help reduce both risk and downtime, contributing to a safer, more productive workplace.

Q: How should the curtains be maintained to ensure reliability?

A: Routine cleaning of the sensor surfaces is recommended to prevent dust or debris from obstructing the photoelectric beams. Regularly verify alignment using the LED indicators and conduct functional tests per manufacturer guidelines to ensure ongoing protection efficiency.

Q: What output and connectivity options are supported?

A: These curtains provide flexible connectivity with options for PNP/NPN transistor outputs and relay outputs. Wired connectivity ensures secure signal transmission, while the extendable 2m cable enhances installation versatility.

Q: When do I need to replace or service the light curtains?

A: Light curtains should be serviced or replaced if they fail self-tests, show physical damage, or if the response times and detection capabilities are compromised. Scheduled preventive checks per the manufacturer's recommendations help maintain optimal safety levels.
